The Centerforce(R) SST (Solid Street Twin) 10.4 Inch multi-disc clutch offers smooth engagement, light pedal, and high-end holding capacity for engine torque levels from 400 to 925 ft /lbs. See extended description for more info.
Please Note: Please Note: Gen III Chrysler Hemi engines and transmissions have a few different variations, including bellhousing depth and starter position. This kit is intended for use with an OE depth bellhousing (i.e. a tall deck) and an OE type starter mounted on the passenger side of the engine. Introducing the NEW Centerforce(R) SST (Solid Street Twin). The SST clutch system has been engineered and developed for vehicles producing 400 to 925 ft/lbs of torque. The SST 10.4" discs utilize solid hubs (possible gear noise) to reduce the rotational weight on the input shaft for quick clean shifts. The discs in this assembly are built using high quality friction materials, for smooth engagement and longevity. The SST features a lightened billet steel flywheel, providing low inertia resulting in quicker RPM and the Centerforce anti-rattle system to reduce floater rattle/noise. No complicated setup or adjustments required, just bolt it in and "Get a Grip". The Centerforce SST includes a billet steel flywheel, 2 discs, floater plate, pressure plate, pilot bearing, alignment tool, and ARP pressure plate and flywheel hardware. The SST clutch system is an economical choice for streetcar enthusiasts looking for a complete high-quality twin disc clutch system. This new clutch assembly can be used for everyday use and spirited days on the track.

Application Summary:

Year Make/Model
2009-2010 Dodge Challenger
2012-2018 Dodge Challenger
Attributes
Alignment Tool Included Yes, Yes
California Proposition 65 WARNING: Cancer - www.P65Warnings.ca.gov
Clutch Disc Diameter 10.4, 10.4, 264.2
Country of Origin (Primary) US
Crankshaft Bolt Hole Quantity 8, 8
Disc Material Organic, Organic
Disc Quantity 2, 2
Disc Type Full Face, Full Face
Disc Type Sprung Solid Solid, Solid
Emission Code Legal US
Flywheel Crank Bolt Size M10 x 1.00 x 25, M10 x 1.00 x 25
Harmonized Tariff Code (Schedule B) 8708935000
Hazardous Material Code N
Input Shaft Diameter 1-1/8, 1-1/8
Input Spline Quantity 26, 26
Life Cycle Status Code Available to Order
Made In The USA Assembled, Assembled
Material Billet Steel Flywheel / Nodular Iron Pressure Plate / Organic Friction, Billet Steel Flywheel / Nodular Iron Pressure Plate / Organic Friction
Mounting Hardware Included Yes, Yes
NAFTA Preference Criterion Code B
Out of Package Weight 51.6
Pilot Bushing Included Yes, Yes
Ring Gear O.D. 13.205, 13.205
Ring Gear Tooth Count 130
SDR Required Flag N
Tooth Quantity 130, 130
Torque Capacity 925, 925
Warranty Time 12
GTIN 00788442036664
